C10 MM SM Fiber Optische Fusion Splicer Machine
Productdetails:
|
|
Plaats van herkomst: | CHINA |
---|---|
Merknaam: | Jiqian |
Certificering: | ISO9001 ROHS CE-EMC FCC SDOC |
Modelnummer: | Splitsers Einddoos 16 Manier |
Betalen & Verzenden Algemene voorwaarden:
|
|
Min. bestelaantal: | 1 stuk |
Verpakking Details: | Binnen plastic geval, buitenkant met cartion |
Levertijd: | 3-5 dagen, hangt het in bestelling af hoeveelheid |
Betalingscondities: | L/C, T/T, Western Union, Alipay |
Levering vermogen: | 2000 stukken per Maand |
Gedetailleerde informatie |
|||
Materiaal: | PVC-ABS | Schakelaartype: | SC FC ST LC UPC |
---|---|---|---|
Type: | 1*2/1*4/1*8/1*16/1*32/1*64 | Toepassing: | Het Netwerk van FTTH FTTB FTTX |
Hoog licht: | FCC FTTB Vezel Optische PLC Splitser,FCC FTTX Vezel Optische PLC Splitser,FTTX 16 Optische PLC van de Maniervezel Splitser |
Productomschrijving
Producteigenschappen:
1.Good uniformiteit en laag toevoegingsverlies
2.Low polarisatie Afhankelijk Verlies
3.Excellent milieustabiliteit
4.Excellent mechanisch
5.Stability Telcordia gr.-1221 en gr.-1209
Toepassing:
1.Fiber aan het Huis (FTTH)
2.Passive optische netwerken (PON)
3.Local gebiedsnetwerken (LAN)
4.Cable televisie (CATV)
5.Test materiaal
Specificatie:
Parameter | Specificatie | ||||||||
Werkende Golflengte (NM) | 1260 ~ 1650 | ||||||||
Type | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 2x4 | 2x8 | 2x16 |
Van het toevoegingsverlies (dB) Max. | ≤4.2 | ≤7.5 | ≤10.6 | ≤13.7 | ≤17.2 | ≤21 | ≤7.8 | ≤10.8 | ≤13.9 |
Maximum uniformiteit (dB) | ≤0.6 | ≤0.8 | ≤1.0 | ≤1.5 | ≤2.0 | ≤2.5 | ≤1.0 | ≤1.5 | ≤2.0 |
Maximum PDL (dB) | <0> | <0> | <0> | <0> | <0> | <0> | <0> | <0> | <0> |
Gerichtheid (dB) Min | 55 | ||||||||
Terugkeerverlies (dB) Min | 55(50) | ||||||||
Werkende Temperatuur (°C) | -45~ +85 | ||||||||
Opslagtemperatuur (°C) | -5~ +75 | ||||||||
Vezellengte | 1m of douanelengte | ||||||||
Vezeltype | Corning G656A1 of Fiberhome G657A1 | ||||||||
Schakelaartype | Gespecificeerde douane | ||||||||
Macht Behandeling (mw) |
300 |
