Name: GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network
Brand: Guangzhou Jiqian Fiber Optic Cable Co., Ltd.
SKU: GCYFY/GCYFTY
Price: 1,249.28 USD
Availability: InStock

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network

1 km

MOQ

Inquiry for price

Prijs

Kenmerken Galerij Productomschrijving Verzoek om een Citaat

Kenmerken

Specificaties

Vezeltelling: 4-144 kernen

Vezeltype: Enkele modus/multi -modus

Jasje: PE/PVC/LSZH/HDPE/MDPE

Kleur: Zwarte of sinaasappel of Aangepast

Productnaam: Lucht-opgeblazen Micro- Kabel

Structuur: Micro- Kabel

Installatie: Leggen van lucht- of kanaalpijpen

Aantal geleiders: ≥ 10

Markeren:

duct installation fiber optic cable

high density network fiber cable

air blown outdoor fiber cable

Basis informatie

Plaats van herkomst: GUANGZHOU, CHINA

Merknaam: JQ/OEM/Customize

Certificering: ISO9001 ROHS CE-EMC FCC SDOC

Modelnummer: GCYFY/GCYFTY

Betalen & Verzenden Algemene voorwaarden

Verpakking Details: Houten trommel/aangepast

Levertijd: 5-8 werkdagen

Betalingscondities: L/C, T/T, Western Union, Alipay

Levering vermogen: 30km per dag

Galerij

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network

Productomschrijving

GCYFY Air Blown Micro Fiber Optic Cable 24 48 96 Core for FTTH Micro Duct Network

Features

Loose tube stranded structure with non-metallic strength member
Designed for air blowing installation in micro ducts
Lightweight and compact for easy deployment
Improves duct utilization and reduces construction cost

Applications

FTTH feeder and drop network installation
Backbone and metropolitan area networks
Access network construction
Connection between distribution points and users

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network 0

Optical Characteristics

Item	Specification
Fiber type	G.652D
Attenuation
@ 1310 nm	≤0.36 dB/km
@ 1383 nm	≤0.35 dB/km
@ 1550 nm	≤0.22 dB/km
@ 1625 nm	≤ 0.30 dB/km
Cable Cut-off Wavelength(λcc)	≤1260 nm
Zero Dispersion Wavelength(nm)	1300 ~ 1324 nm
Zero Dispersion Slope	≤0.092 ps/(nm2.km)
Chromatic Dispersion
@ 1288 ~ 1339 nm	≤3.5 ps/(nm. km)
@ 1550 nm	≤18 ps/(nm. km)
@ 1625 nm	≤22 ps/(nm. km)
PMDQ	≤0.2 ps/km1/2
Mode Field Diameter @ 1310 nm	9.2±0.4 um
Core Concentricity Error	≤0.6 um
Cladding Diameter	125.0±0.7 um
Cladding Non-circularity	≤1.0%
Coating Diameter	245±10 um
Proof Test	100 kpsi (=0.69 Gpa), 1%

Fiber & Tube Color

Environmental Characteristics: • Transport/storage temperature: -40℃ to +70℃

Cable Parameters

Cores

Cores/tube

FRP diameter (mm)

Sheath thickness (mm)

Approx. overall diameter

(mm)

Approx.

weight (kg/km)

1.5

0.5±0.1

5.6

1.5

0.5±0.1

5.6

48	12	1.5	0.5±0.1	5.6	24
72	12	1.5	0.5±0.1	5.6	24
96	12	2.5	0.5±0.1	6.6	38

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network 3

Delivery Length

• Standard length: 4,000m; other lengths are also available.

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network 4

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network 5

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network 6

GCYFY Air Blown Fiber Optic Cable 24 48 96 Core for Duct Installation High Density Network 7

Welcome to your Inquiry Welcome to visit our factory!

FAQ – GCYFY Air Blown Micro Fiber Optic Cable

Q1: What is GCYFY fiber optic cable used for?
A: It is mainly used for FTTH, access networks, and micro-duct air blown installations.

Q2: What fiber counts are available?
A: Common options include 24, 48, and 96 cores, with customization available.

Q3: How is the cable installed?
A: It is installed by air blowing into pre-installed micro ducts.

Q4: Is the cable suitable for long-distance networks?
A: Yes, it is designed for backbone, metropolitan, and access network deployment.

Q5: What are the advantages of air blown installation?
A: It improves duct utilization, reduces construction costs, and allows easy network expansion.
